774980 Optical sight VOMZ Pilad 8x56 LFC (rangefinder reticle) Код товара: 36-41-10638

VOMZ Pilad 8x56 LFC optical sight (rangefinder reticle)

Magnification, x 8
Lens diameter, mm 56
Field of view, ° 3°20'
Removal of the exit pupil, mm 74
Exit pupil diameter, mm 7
Eyepiece refocusing limit, diopter ±5
Operating temperature, ° C -40°С ... +50°С
Nitrogen filling No
Reticle illumination Yes
Battery type 2 cells type SP43P or UKAR 386, VARTA 528, AG12
Overall length, mm 310
Weight, g 550
Tube diameter, mm 25.4
Additional information: Reticle illumination/ Field of view at 100 m - 11.6 m/ Twilighte number - 21.17
Warranty, month 12
Country of manufacture Russia

The main purpose of the optical sight PLALAD 8x56 LFC

The Russian-made optical sight PILAD 8x56 LFC is equipped with a powerful lens that provides a clear image of the target at a distance of 30 m even during the week residual level of natural light. An 8-fold magnification allows accurate shooting at a distance of up to 200-250 m.

Scope of application: hunting from prepared positions, recreational or sports target shooting, varminting.

The illumination of the "parabola" sighting reticle is a convenient option for hunting during the dawn-dusk period orfor shooting at targets against a dark background (for example, against a background of foliage or forest).

Basic characteristics of the optical sight PLALAD 8x56 LС

• 8x magnification, 56mm lens, 74mm eye relief
• Diopter adjustment +5 diopter
• Adjustment from parallax on the lens, distance without parallax - 15 m
• Vertical and horizontal correction drums, alignment step - ¼ t.d. (25mm/100m)
• Aiming reticle "parabola" with backlighting, 9 degrees of brightness, power supply - 2 elements of type SP43P or UKAR 386, VARTA 528, AG1 2
• Impact-resistant shell, 25.4 mm mount diameter
• Supplied with a rubber eyecup, lens and lens caps

Constructive features of the optical sight PLALAD 8x56 LС

A bright lens with a diameter of 56 mm provides a sufficiently bright and sharp image even with insufficient natural lighting.

It has a mechanism for additional focusing on the lens, which allows you to adjust the sharp image of the target at a distance of 15 m.

This model uses a parabola reticle, which has 2 rangefinding scales.

Alignment of the grid horizontally and vertically is carried out with the help of 2 adjustment drums.
