РШАВКП 20-3 Connector (male) fork RSHAVKP 20-3 Код товара: 86-117-6411

Name RSHAVKP-20-3 Fork
Function group Low frequency rectangular
Functional type fork
Rating / Type design straight cable plug
Number of pins or contacts 20
Casing or spigot type metal casing
Mating Method Plug
Minimum running time 500 hours.
Life 5000 cycles
Minimum shelf life, years 20
Working position any
Release date 01.01.1984
Trademark of OAO "Karachevskiy Zavod "Elektrodetal"
Country of origin USSR
Project typeTanks "5"
Passport - no label
Climatic version UHL 2.1
Actual marking RSHAGKP-20-3
Complete set
Product weight, gr. 145
Type of packaging self-packing
Product color brown
Operating temperature range from +85 to -60 °С
Relative humidity 98%
Overall dimensions L*W*H 89х87
Housing material carbolite
Contact resistance max. 10 mΩ
Rated voltage 600 V
Operating current 6 A

Volumetric mounting connector RSHAGKP-20-3 is designed for operation in electrical circuits.yah direct, alternating (frequency up to 3 MHz) and impulse current. The plug is equipped with a universal metal housing and has a direct cable exit. The case is dustproof. A sleeve is used to fasten the cable in the housing. To fix the articulated position, the socket has special clips. The housing connector is designed for outdoor installation.
