РП14-10ЛО Connector RP14-10LO socket Код товара: 86-117-6421

General Information

Name RP14-10LO Rosette
Trademark PO "Elbrus", Izobilny
Country of origin USSR
TU bRO.364.024 TU
Acceptance type "1"
Release date 01.01.1987
Transliteration RP14-10LO

Main parameters

Function group Low frequency rectangular
Type rating / Type design rosette
Knife contact type
Number of pins or contacts 10
Ag plating (silver)
Type of casing or spigot without casing
Cutting joint method
Mounting method three-dimensional
Actual marking RP14-10LO
Product color brown
Overall dimensions L*W*H 53х32х18 mm
Product length 53 mm
Product width 18 mm
Housing material carbolite
The presence of a lock for fixing no
The presence of catchers (guide pins, bushings) is
The presence of the body is not

Specifications

Operating frequency range 1 - 3000 Hz
Contact resistance max. 30 mΩ
Insulation resistance not less than not less than 5000 MΩ
Rated voltage 800 V
Operating current 5 A percontact
Note fasteners included
