102 channel fireworks remote control Код товара: 83-84-1072

SPECIFICATIONS:

Number of channels (total) -100

Number of main channels-100

Number of additional (direct) channels

Number of additional channels for stage pyrotechnics-2

Supply voltage (Uvkh)-24 V

Current consumption in standby mode without control panel backlight (no more) -200mA

Backlit control panel-300mA

The maximum allowable current on the main channels at tْ + 20ْC-5A ± 5%

Maximum allowable current on additional channels (for stage pyrotechnics) at tْ +20ْC-6А ± 5%

The maximum number of electric igniters that are guaranteed to fire simultaneously on one channel:

- with a resistance of electric igniters 2.5 - 3 Ohm-10 pcs

- with a resistance of electric igniters 1 Ohm-1 pc

The maximum battery charging current is 0.4 A

Battery capacity-2.3Ah
