100 channel firework remote control Код товара: 83-84-1068

SPECIFICATIONS:

Number of channels (total) - 100

Number of main channels - 100

Power supply voltage (Uin) - 24 V

Current consumption in standby mode without control panel backlight (no more) -200mA

Illuminated control panel-300mA

The maximum allowable current on the main channels at tْ +20ْC-5A ± 5%

Maximum number of electric igniters guaranteed to fire simultaneously on one channel :

- with a resistance of electric igniters 2.5 - 3 Ohm-10 pcs

-withresistance of electric igniters 1 Ohm-1 piece

The maximum battery charging current is 0.4 A

Battery capacity - 2.3Ah

The remote control is equipped with a system of protection against self-induction in the cables when the power is turned on and protection against short circuits on each channel.

Conventions and abbreviations:

EV - electric igniter,

Short circuit - short circuit.
