Pulsar Challenger GS 2.7x50 Night Vision Features:
Image intensifier tube type: CF-Super/EP33-SF
Magnification, times: 2.7
Lens diameter, mm: 50
· Resolution (on the center/on the edge of the field of view), lines/mm: 42/36
· Field of view angle, ang. deg: 13
Maximum detection distance, m: 150
Exit pupil diameter, mm: 6
Removal of the exit pupil, mm: 12
Eyepiece refocusing limit, diopter: ±4
Operating voltage / type of pit cellsniya: 3V (1хCR123A)
Battery life (IR off/on), h: 72/20
Operating temperature range, °С: -20...+ 40
Overall dimensions, mm: 202х79х57
Weight, kg: 0.5
NVD Pulsar Challenger GS 2.7x50 description:
The Challenger GS 2.7x50 is based on an ingenious combination of custom-designed optics, a CF-Super image intensifier tube and a wide-angle five-lens eyepiece. As a result - no distortion (distortion of the image), clarity and geometric accuracy of the imageover the entire field of view, high resolution. The case of the device is sealed, which allows using the Challenger GS 2.7x50 in adverse conditions (during fog, in heavy rain, in places with a high concentration of dust, in sandstorm conditions).
The Challenger GS 2.7x50 is equipped with a powerful IR illuminator that can be used outdoors.Insufficient lighting conditions for observation at distances above average. The device also has a seat for installing additional, more powerful, focusable Pulsar infrared illuminators. On/off operations of the device and the IR illuminator are carried out using a common switch. The design of the switch provides protection against accidental activation of the IR illuminator (to prevent the unmasking of the observer).
Challenger GS 2.7x50 / 3.5x50 applications are varied. This is a night orienteering tour.zm, hunting, protection of industrial facilities and private property, military sports games, patrolling, search and rescue.
